Bi-Leveling Tracked Scissor Lift - Self-Leveling Aerial Platform

Bi-leveling tracked scissor lifts, also recognized as self-leveling or automatic leveling rough terrain scissor lifts, represent advanced aerial access technology designed for challenging terrain applications. These innovative aerial platforms provide safe and efficient access to elevated areas with automatic leveling capabilities, making them ideal for uneven terrain and slopes. Equipped with sophisticated bi-leveling technology and compact design, these lifts operate effectively in confined spaces with maximum working heights reaching 14 meters.

Advanced Dual Scissor Arm Technology

The bi-leveling system features dual scissor arms connected to an integrated track system, enabling smooth vertical movement and lateral positioning capabilities. Electric motor operation with remote control functionality provides precise positioning for accessing ceilings, walls, and elevated surfaces. The track system delivers superior mobility across challenging terrain while maintaining platform stability throughout operation.

Professional Bi-Leveling Advantages

One-Key Automatic Leveling Advanced leveling function provides seamless operation on rough terrain environments through intelligent automatic adjustment, eliminating manual leveling requirements and reducing setup time.

Extended Platform Capability The working platform extends to navigate around obstacles and reach confined areas, providing enhanced accessibility compared to traditional fixed-platform aerial equipment.

Slope Operation Performance Engineered for operation on narrow working spaces and slopes up to 20% grade, enabling access to challenging terrain where conventional aerial platforms cannot operate safely.

Comprehensive Safety Systems Integrated overload warning, remote control operation, and one-key emergency stop functionality ensure maximum operator safety and equipment protection during all phases of operation.

Compact Track Design Rubber track system provides excellent traction and ground protection while maintaining compact dimensions for operation in restricted access areas and sensitive surface environments.

Electric Power Efficiency Clean electric operation eliminates emissions and reduces noise levels, making bi-leveling tracked scissor lifts ideal for indoor applications and environmentally sensitive work zones.

Versatile Application Solutions

Bi-leveling tracked scissor lifts excel in construction, maintenance, industrial facility work, and specialized access projects requiring automatic leveling on uneven terrain. The combination of track mobility, self-leveling technology, and compact design makes these aerial platforms perfect for challenging environments where traditional wheeled equipment cannot provide stable operation.

Professional bi-leveling tracked scissor lift models offer reliable solutions for businesses requiring advanced aerial access capabilities in demanding terrain conditions.

Model	Z08TSL	Z10TSL	Z12TSL
Rated Load	250kg	250kg	250kg
Max Platform Height	8.3m	10m	12m
Max Working Height	10.3m	12m	14m
Machine Length	2530mm	2530mm	2530mm
Machine Width (Retracted)	1770mm	1770mm	1770mm
Machine Height (Retracted)	2432mm	2582mm	2712mm
Platform Dimensions	2280×1136×1260mm	2280×1136×1260mm	2280×1136×1260mm
Length of Extended Platform	900mm	900mm	900mm
Weight	3398kg	3698kg	3998kg
Battery	8×6V (200Ah)	8×6V (200Ah)	8×6V (200Ah)
Charger	30A	30A	30A
